Description
| Material | Galvanized |
| Usage/Application | Commercial Buildings, Residence Apartment |
| Dimension/Size | 84mm W x 15mm D x L up to 5m |
| Panel Material Thickness | 0.71 mm |
| Panel Material | Aluminium alloy 8011-H3 |
| Carrier Dimension | 38mm W x 98mm D x 0.6 mm |
| Finishing | Powder Coated |
| Brand | VINDSIL |
| Appearance | Modular |
| Minimum order quantity | 2000 sq ft |
Panel Details (Galvanized Steel)
Vindsil make 84 R, Round edge panels, 84mm wide x 15mm deep x length up to 5mtr. formed out of 0.55 mm thick (TCT) Galvanized Steel as per IS-513 fixed on Louver Carriers. Panels shall be powder coated on both the surfaces with special exterior SUPERCOTE powder to enhance property of Fadeness Resistivity.
Carrier Details (SL-5)
Black enameled Galvanized Steel Carrier of 38mm wide x 98mm deep x 0.6 mm thick in a standard length of 8’ with cutouts to hold the panel in a module of 74 mm centre to centre at a distance of 1 mtr. Carrier and Suitable structure shall be powder coated on exterior face to enhance properties of Fadeness and corrosion resistivity.
Installation Details
GS clit shall be fixed on Vertical Columns with dash fasteners at distance not more than 1 mtr. Centre to centre on which Tubular Stud sections will be laid with corrosion proof screws and on this rigid structure carrier shall be fixed vertically at distance of 1 mtr. Centre to centre. Panel shall be clipped to black carriers.
