₹128.00 sq/ft
Technical Specification
Manufacturers Specification for Supersil U Shaped Screen 100*50*100 mm (100mm Gap between two Panels) Open False Ceiling System.
Panel Details (Aluminium)
Supersil make Square edge panels, 50 mm wide x 100 mm deep x length up to 2.5 mtr. With formed out of 0.7 mm thick (TCT) aluminium alloy (AA) 8011-H3 fixed on carriers. Panel shall be powder coated on external surface only.
Panel Details (Galvanized Steel)
Supersil make Square edge panels, 50 mm wide x 100 mm deep x length up to 2.5 mtr. With formed out of 0.50 mm thick (TCT) galvanized steel fixed on carriers. Panel shall be powder coated on external surface only.
Carrier Details:Carrier, 24 mm wide at the bottom x 42 mm deep formed out of 0.50 mm thick galvanized steel sheet stove enameled black with protruding ears to hold the panels in a module of 150 mm.
The carrier shall be suspended from slab by 4 mm dial galvanized rod with special height adjustment powder coated clips made out of spring steel at maximum 1.2 to 1.5 mtr. Centre to centre. The 4mm dia galvanized rod shall be fixed to slab by forming one end “J” shape with roll inserts.
U SHAPED 100*50*100
| Specification | Details |
| Material | Aluminium |
| Usage/Application | Sound Absorbers |
| Thickness | Alu 0.70mm & GI 0.50mm |
| Country of Origin | Made in India |
| Surface Treatment | Powder Coated |
| Manufacturing Technique | Cold Rolled |
| Usage of panel | U Shape Baffle Ceiling- Fixed Length |
| Coating | Powder Coating |
| Corrosion Resistant | YES |
| Fire Retardant | YES |
| Max Size | 3660 MM |
| Minimum order quantity | 10000 sq ft |
