Unique linear ceiling

₹150.00 sq/ft

Here’s a more detailed breakdown of linear ceiling product specifications:

Materials

Common Materials
Aluminum, steel, wood, or mineral fiber.

Benefits
Metal (like aluminum) is durable and often used for acoustic ceilings, while wood offers a warm aesthetic. Mineral fiber is often used for its sound-absorbing properties.

Fire Resistance

Fire-Rated Materials
Panels may be rated for fire resistance, which is essential for public spaces and buildings that need to meet fire safety standards.

Compliant with Standards
Look for compliance with standards like ASTM E84 (standard fire test), and local regulations.

Lighting Integration

Integrated Lighting
LED strips can be seamlessly incorporated into the grid or between panels, enhancing the design with indirect lighting.

Flush or Recessed
Linear lighting can be embedded directly into the ceiling system for a clean, modern look.

Customizable Light Fixtures
Some systems allow for customizable light placements, providing options for creating ambiance or focusing light.

Product Brochure

Category:

Description

Product Details

Specification Details
Panel Width 84C
Material Galvanized Steel
Surface Finish Powder Coated
Panel Length upto 10 ft
Panel Dimension vertical/horizontal
Perforation Details 1.8 mm standard perforation
Brand vindsil
Ceiling Type LINEAR CEILING
Corrosion Resistance no
Fire Retardant fire proof
Thickness 0.5/0.65
Usage/Application residential
Minimum order quantity 10000 sq ft

Finish Options

Powder-Coated Metal
A durable, smooth finish available in various colors.

Wood Veneer
Adds a natural look, with finishes that mimic wood or other textures.

Perforated Panels
Offers both aesthetic appeal and acoustic performance.

Dimensions

Length
Typically ranges from 1 meter to 4 meters, but custom lengths can be requested.

Width
Panels can vary from 100mm to 300mm wide.

Thickness
Usually between 1mm and 2mm, with thicker panels offering more sound insulation and durability.

Acoustic Performance

NRC (Noise Reduction Coefficient)
Typically ranges from 0.5 to 0.85 for good sound absorption in commercial spaces. High NRC values are ideal for open offices or auditoriums.

Sound Absorption
Some systems incorporate sound-absorbing backer panels or perforations to improve acoustic control.

Example Specification

Material
Perforated aluminum with powder-coated white finish.

Panel Dimensions
3000mm length x 200mm width x 1.5mm thickness.

Suspension Type
Ceiling grid system, 600mm centers.

Acoustic Performance
NRC of 0.8, good sound absorption for office spaces.

Lighting Integration
Recessed LED strips along the grid.

Fire Rating
Class A (ASTM E84).

Sustainability
Made from 50% recycled content, LEED compliant.

Use Cases

Office Spaces
For a modern, clean aesthetic with good acoustic control.

Retail Stores
Helps create a high-end look while integrating lighting.

Public Areas
Can be used in large spaces that need noise control and visual appeal.
