Linear 84-C/184-C

Linear 84C from the varieties of metal linear ceiling options has been used as a worthwhile option on exterior and interior architecture and gives the designers, a considerable option for visual design continuity. The panels hook into the concealed suspension system to form a closed joint linear ceiling. It will give a satisfactory rhythm to any project, where colors & length come together. Architects can fulfil with ease, several acoustical criteria with the insertion of acoustical inlays.


  • Material:
    Galvanized Steel 0.5mm, Aluminimum 0.65mm
  • Panels:
    Square edge, 84mm wide, 13mm deep, length up to 5mtr
  • Carrier:
    Carrier shall be 20 mm wide and 45 mm deep of 0.5mm Galvanized Steel stove enameled black to hold Panel in module of 100 mmm.
  • Paint Finish:

    55 microns thick powder coating on exposed surface or 25 microns polyester coil coated over primer on visible surface with primer coat on rear side.
