Linear 84-C/184-C
Linear 84C from the varieties of metal linear ceiling options has been used as a worthwhile option on exterior and interior architecture and gives the designers, a considerable option for visual design continuity. The panels hook into the concealed suspension system to form a closed joint linear ceiling. It will give a satisfactory rhythm to any project, where colors & length come together. Architects can fulfil with ease, several acoustical criteria with the insertion of acoustical inlays.
- Material:
Galvanized Steel 0.5mm, Aluminimum 0.65mm - Panels:
Square edge, 84mm wide, 13mm deep, length up to 5mtr - Carrier:
Carrier shall be 20 mm wide and 45 mm deep of 0.5mm Galvanized Steel stove enameled black to hold Panel in module of 100 mmm. - Paint Finish:
55 microns thick powder coating on exposed surface or 25 microns polyester coil coated over primer on visible surface with primer coat on rear side.
